Approaching serous PED

Serous PED is a result of fluids leak via Bruch’s membrane to space between Bruch’s and RPE, causing an increased in hydrostatic pressure separating RPE from Bruch’s membrane.

Fundus image

On clinical examination, a smooth, well-defined border of RPE elevation along with a slight pale appearance
PED is associated with subretinal fluid or intraretinal hemorrhage.

Fundus image showing serous PED with subretinal fluids and drusen

Optical coherence tomography

On OCT, PED features smooth or irregular RPE elevation, which contains clear fluids that looks like a homogeneous hyporeflective area. PED may feature sub / intraretinal fluids accompanied by ellipsoid zone disruption.

OCT cross-section showing serous PED with subretinal and intraretinal fluids

Fluorescein fundus angiography

On FFA, serous PED shows a distinct area of early hyperfluorescence, which increases in the mid and late phase due to dye pooling.

FFA is useful to detect the presence of neovascular membrane.

Fundus image showing serous PED and subretinal fluid and hemorrhage

Early phase FFA showing early hyperfluorescence from CNV and subretinal fluids

Mid phase FFA showing increased hyperfluorescence from CNV, subRPE and subretinal fluids

Late phase FFA showing increased hyperfluorescence from CNV with subRPE pooling increasing in intensity without changing it borders or leaking and subretinal fluids pooling

Management

Treating serous PED is a clinical challenge with poor prognosis; however, better treatment response to VEGF trap (Aflibercept or Conbercept) in contrast to Anti VEGF (Bevacizumab or Ranibizumab).
If PED presented without any other retinal features such as active CNVm does not warrant treatment as regressing PED alone won’t improve vision or prognosis.

Please check Clinical guidelines for ARMD and course of clinical changes in RPE

Comments

Cellophane maculopathy

Caused by an epiretinal membrane, clinically, it appears as a sheen abnormal foveal reflex which features epiretinal membrane, due to inflammatory mediators and proliferation of glial cells secondary to a partial separation of posterior cortical vitreous. Fundus image shows cellophane maculopathy OCT features a hyperreflective band covering the inner retinal layers, causing minimal disturbance of inner retinal tissues. OCT cross-section shows epiretinal membrane Cellophane maculopathy itself in individuals with good visual acuity may not need any interventions, but it is warranted to do a detailed peripheral retinal exam to rule out retinal tear or hole However, an epiretinal membrane may proliferate further and cause additional tangential traction. Thus, it may induce macular pucker or lamellar/pseudo hole and increase disturbance of inner retinal tissues, macular thickness, and reduction of vision. These patients may require pars plana vitrectomy to remove the epiretinal membrane an

RPE tear, and it's OCT features in a nutshell

RPE tear can occur in vascularized PEDs due to a complication of intravitreal AntiVEGF treatment, which causes a rapid contraction of CNVm, inducing traction on the RPE surface and shrinking of RPE surface. On OCT, the RPE rip will indent the retina with increased hyperreflectivity in contracted RPE with underlying shadowing hinders choroidal view in contrast to the area where RPE where it ripped of which only Bruch's membrane is visible and increasing the visibility of the underlying choroid. RPE tear Thus two opposite forces, the regression of CNVm and remaining attached RPE, other causes such as laser or spontaneous can occur. However, the AntiVEGF treatment continued despite the RPE tear. Please check Clinical guidelines for ARMD and course of clinical changes in RPE

Diabetic macular edema with ischemic changes associated with very severe NPDR

A 51 years old male known to be diabetic for ten years with excellent glycemic control profile along with normal blood pressure presented with BCVA 20/100 in his left eye; he had a better vision of 20/30 in the same eye one year ago when he used to be on intravitreal injections of aflibercept, but he decided to discontinue intravitreal injection as been advised by another physician. Fundus image His fundus image shows cystic formation at the fovea with a sign of intraretinal dot and blots hemorrhages in the mid periphery with cotton wool spots and IRMA (Intra Retinal Microvascular Abnormalities). Fundus image showing macular edema with intraretinal hemorrhage and cotton wool spots Optical coherence tomography His OCT scan shows thickened central macular tissues with disorganization of inner retinal layers and non-empty cystic formation as it is classic findings of diabetic macular edema with some empty cystic formation; however, the ellipsoid zone looks intact. OCT cross-section for ce
